Danyang Kaixin Alloy Material Co., Ltd.
3 Years
| Ask Lasest Price | |
| Brand Name : | KAIXIN |
| Model Number : | KX-Alloy NICr4 |
| Certification : | ISO9001:2015 |
| Price : | To negotiate |
| Payment Terms : | T/T, L/C |
| Supply Ability : | 50~80TONS per MONTH |
| Delivery Time : | 45~60days |
Product Description and Application
Cr30Ni70 contains 20% Cr and 80% Ni, which has excellent comprehensive performance. High-quality heating element will choose Cr30Ni70, which has the advantages of good oxygen resistance, high strength, non-magnetic, high emissivity, good corrosion resistance, no softening, no deformation, low permanent elongation. It is mainly used for periodic heat treatment furnace with working temperature below 1000℃, such as carburizing furnace, hood furnace, ammonia decomposition furnace, and also used for metallurgy, household appliances, machinery manufacturing and etc advanced heating components, which is as advanced resistance materials in the electrical industry. It is suitable for resistance tape in high quality resistance boxes. It also can be used as high quality heat resistant steel structural parts, such as high temperature resistant mesh belt, burning frame and etc.
Process Performance and Requirements
Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)
| Alloy Grade | Chemical Composition (Mass fraction)% | ||||||||
| C | P | S | Mn | Si | Cr | Ni | Al | Fe | |
| ≤ | |||||||||
Cr30Ni70 | 0.08 | 0.020 | 0.015 | 0.60 | 0.75-1.60 | 28.0-31.0 | Rem | ≤ 0.50 | ≤ 1.0 |
| Room Temperature Resistivity of High Resistance Electrothermal Alloy Wire | ||
| Alloy Grade | Diameter/mm | Resistivity(20℃ hour)/(10-52-m) |
Cr30Ni70 | < 0.50 | 1.18±0.05 |
| ≧0.50 | 1.20±0.05 | |
| Room Temperature Resistivity of High Resistance Electrothermal Alloy Strip | ||
| Alloy Grade | Alloy Strip Thickness/mm | Resistivity(20℃ hour)//(10⁻6Ω-m) |
Cr30Ni70 | <0.80 | 1.18±0.05 |
| >0.80-3.00 | 1.19±0.05 | |
| >3.00 | 1.20±0.05 | |
Professional Customization
| Cold-drawn Wire | ¢0.3~¢18mm(Delivery in rolls or trays) |
| Hot-Rolling Wire | ¢5.5~¢20mm(Delivery in rolls) |
| Strip | thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips) |
| Smooth Forged Rod on a Lathe | ¢60~350mm,L800-2500mm |
| Hot-rolled Burnishing | ¢20~80mm,L1000-5000mm |
| Cold Drawn and Burnishing | ¢2.5~18mm,L1000-8000mm |
| Seamless Tube | ¢1~275mm,wall thickness 0.2~30,L1000-8000mm |
|
|
