Product Description and Application
"GH2747" is also known as FeNicr2747, "P 747" (RU)
GH2747 (GH747) is Fe-Ni-Cr based precipitation-hardened deformation superalloy, which is used in the state of solid solution. Its long-term operating temperature is 1100°C-1250°C and short-term use temperature up to 1300°C. It has high strength, good structure stability, excellent oxidation resistance and corrosion resistance. The alloy weldability is good and various processes can be used for welding. GH2747 alloy has been used in the production of high temperature oxidation resistance components in the aerospace engine combustion chamber and afterburner, as well as in the production of various industrial furnace rolls, transmission devices, thermocouple sleeves and etc heat-resistant components, especially suitable for high-temperature anti-oxidation device parts in petrochemical, nuclear energy, metallurgy and etc fields.
Process Performance and Requirements
Vacuum Induction Furnace(VIM) and Electroslag Remelting Furnace(ESR)
| Alloy Grade | C | Mn | Si | P | S | Ni | Cr |
| GH2747 | ≤ 0.1 | ≤ 1.0 | ≤ 1.0 | ≤ 0.025 | ≤ 0.020 | 44.0～46.0 | 15.0～17.0 |
| Al | Ce | Ti | Mo | Co | Fe | ||
| 2.9～3.9 | ≤ 0.030 | - | - | - | Rem |
| Density | 7.78g/cm3 |
| Melting Point | 1400-1425℃ |
| Magnetic Energy | Nil |
Standard heat treatment: The alloy is used in the state of solid solution. The heat treatment institution is 1000°C-1200°C. The protection time is determined by the material size.
| Standard number | Variety | Heat Treatment | θ / ℃ | Tensile Property | |||
| MPa | MPa | % | % | ||||
| Q/GYB 511 | Hot-rolled and Forged Bar | Standard | 20 | ≧550 | ≧200 | ≧15 | ≧20 |
| 1000 | ≧40 | ≧20 | ≧30 | ≧30 | |||
| Q/GYB 512 | Cold-rolled Seamless Pipe | 20 | ≧600 | --- | ≧30 | --- | |
Professional Customization
| Cold-drawn Wire | ¢0.3~¢18mm(Delivery in rolls or trays) |
| Hot-Rolling Wire | ¢5.5~¢20mm(Delivery in rolls) |
| Strip | thickness 0.1~4.5*width 6~350mm(Supply in rolls or straight strips) |
| Smooth Forged Rod on a Lathe | ¢60~350mm,L800-2500mm |
| Hot-rolled Burnishing | ¢20~80mm,L1000-5000mm |
| Cold Drawn and Burnishing | ¢2.5~18mm,L1000-8000mm |
| Seamless Tube | ¢1~275mm,wall thickness 0.2~30,L1000-8000mm |
|
|
